| Indoor | Outdoor | ||||
| Product | P2.604 | P2.976 | P3.91 | P3.91 | P4.81 |
| Pitch | 2.604mm | 2.976mm | 3.91mm | 3.91mm | 4.81mm |
| Density (pixels/㎡) | 147456 | 112896 | 65536 | 65536 | 43264 |
| LED | SMD1515 | SMD2121 | SMD2121 | SMD1921 | SMD1921 |
| Brightness | 900nits | 900nits | 900nits | 5000nits | 5500nits |
| Scanning Method | 1/32 | 1/28 | 1/16 | 1/16 | 1/13 |
| Cabinet Size | 500*1000*75mm (500*500*75mm optional) | ||||
| Cabinet pixel | 192*384 | 168*336 | 128*256 | 128*256 | 104*208 |
| Module Size | 250*250mm | 250*250mm | |||
| Module Pixel | 96*96 | 84*84 | 64*64 | 64*64 | 52*52 |
| Cabinet Material | Die-cast aluminum | ||||
| Pitch | 2.604mm | 2.976mm | 3.91mm | 3.91mm | 4.81mm |
| Cabinet Weight | 12kg | 13kg | |||
| Cabinet Maintenance | Front&Rear Service | Rear Service | |||
| Maximum Power Consumption | 600 w/㎡ | 800 w/㎡ | 700 w/㎡ | 800 w/㎡ | 800 w/㎡ |
| Average Power Consumption | 200 w/㎡ | 270 w/㎡ | 240 w/㎡ | 270 w/㎡ | 270 w/㎡ |
| Refresh Rate（Hz） | 3840Hz | ||||
| Grey Scale | 16bit | ||||
| Viewing Angle | H160°, V160° | H160°, V140° | H160°, V140° | H140°, V140° | H140°, V140° |
| Voltage | AC100~240V(50-63Hz) | ||||
| Working Temperature | ﹣30℃－﹢65℃ | ||||
| Working Humidity | 10%－90%RH | ||||
| Color Temperature | 6500-9500K | ||||
| Certifications | EMC/CE/ROHS/CCC/FCC/ISO | ||||
